1/2” DRIVE Standard Length  Impact Sockets, 6-point, METRIC

1/2” DRIVE Standard Length Impact Sockets, 6-point, METRIC

Code

Size

D1

D2

T

L

Type

(mm)

(mm)

(mm)

Min (mm)

(mm)

72008

8

14

25

11

38

A

72009

9

15.2

25

14

38

72010

10

17.2

25

14

38

72011

11

18.2

25

14

38

72012

12

20

25

14

38

72013

13

21

25

14

38

72014

14

22.2

25

19

38

72015

15

24

30

19

38

72016

16

24

30

19

38

72017

17

26

30

19

38

72018

18

27.2

30

19

38

72019

19

28

30

19

38

72020

20

29.6

30

19

38

72021

21

29.8

30

21

38

B

72022

22

31.8

30

21

38

C

72023

23

33.6

30

21

38

72024

24

33.8

30

21

38

72025

25

35

30

21

38

72026

26

35.6

30

21

38

72027

27

37.7

30

21

40

72028

28

39.8

30

24

43

72029

29

39.8

30

24

43

72030

30

41.8

30

24

43

72032

32

43.8

30

24

43

72033

33

44.8

30

24

46

72034

34

45.8

30

24

46

72035

35

47.8

30

24

50

72036

36

49.8

30

24

50

72038

38

51.8

30

24

50

1/2” Drive Standard Impact Sockets, 6-point, Imperial

1/2” Drive Standard Impact Sockets, 6-point, Imperial

Code

Size

D1

D2

T

L

Type

(inches)

(mm)

(mm)

Min (mm)

(mm)

72058

5/16

14

25

9

38

A

72059

3/8

17

25

9

38

72060

7/16

18.5

25

9

38

72061

1/2

20.5

25

9

38

72062

9/16

23

25

11

38

72063

5/8

24.5

30

11

38

72064

11/16

27

30

11

38

72065

3/4

28

30

11

38

72066

13/16

30

30

11

38

B

72067

7/8

31.8

30

13

38

C

72068

15/16

33.8

30

13

38

72069

1

35.8

30

13

40

72070

1-1/16

37.8

30

13

43

72071

1-1/8

39.8

30

16.5

43

72072

1-3/16

41.8

30

16.5

43

72073

1-1/4

43.8

30

16.5

43

1/2” Drive Deep Impact Sockets, 6-point, Metric

1/2” Drive Deep Impact Sockets, 6-point, Metric

Code

Size

D1

D2

T

L

Type

(mm)

(mm)

(mm)

Min (mm)

(mm)

72108

8

14

25

9

80

A

72109

9

16.6

25

11

80

72110

10

17

25

11

80

72111

11

18.5

25

11

80

72112

12

20

25

11

80

72113

13

21

25

11

80

72114

14

22.4

25

11

80

72115

15

23

30

11

80

72116

16

25

30

11

80

72117

17

26

30

11

80

72118

18

27.5

30

11

80

72119

19

28.5

30

13

80

72120

20

30

30

13

80

B

72121

21

31.9

30

13

80

C

72122

22

31.8

30

13

80

72123

23

31.8

30

13

80

72124

24

34.8

30

15

80

72125

25

35.8

30

15

80

72126

26

35.8

30

15

80

72127

27

37.8

30

18.3

80

72128

28

39.8

30

18.3

80

72129

29

41.8

30

18.3

80

72130

30

42

30

18.3

80

72132

32

44

30

18.3

80

72133

33

44.8

30

20

80

72134

34

45.8

30

20

80

72135

35

47.8

30

20

80

72136

36

49.8

30

20

80

72138

38

51.8

30

20

80

1/2” Drive Deep Impact Sockets, 6-point, Imperial

1/2” Drive Deep Impact Sockets, 6-point, Imperial

Code

Size

D1

D2

T

L

Type

(inches)

(mm)

(mm)

Min (mm)

(mm)

72158

5/16

14

25

10

78

A

72159

3/8

17

25

14

78

72160

7/16

18.5

25

14

78

72161

1/2

20.5

25

14

78

72162

9/16

23

25

14

78

72163

5/8

24.5

30

14

78

72164

11/16

27

30

17

78

72165

3/4

28

30

17

78

72166

13/16

29.8

30

17

78

B

72167

7/8

31.8

30

19

78

C

72168

15/16

33.8

30

19

78

72169

1

35.8

30

19

78

72170

1-1/16

37.8

30

19

78

72171

1-1/8

39.8

30

19

78

72172

1-3/16

41.8

30

19

78

72173

1-1/4

43.8

30

30

78

Rectangle Impact Sockets

Rectangle Impact Sockets

3/4″ Drive

72200 – 19 x 21mm Standard Length

72201 – 19 x 21mm Deep Length

72202 – 21 x 28mm Standard Length

72203 – 21 x 28mm Deep Length


1″ Drive

72615 – 19 x 21mm Standard Length

72616 – 19 x 21mm Deep Length

72617 – 21 x 28mm Standard Length

72618 – 21 x 28mm Deep Length
